Arduino UNO R4 Minima

  1. Same form factor as UNO R3
  2. Extra onboard peripherals
  3. Inbuilt HID Support
  4. Expanded Memory and Faster Clock Speed than before

EGP850.00

In stock

SKU: C08-11-MINIMA Categories: ,
Estimated delivery dates: 03-12-2024 - 05-12-2024

Introducing the Arduino UNO R4 Minima, a groundbreaking addition to the UNO board family. This new launch boasts impressive features, starting with its 32-bit microcontroller. Powered by the RA4M1 series microcontroller from Renesas (R7FA4M1AB3CFM#AA0), which houses a 48 MHz Arm Cortex-M4 microprocessor.

Pin Configuration:

The UNO R4 Minima offers expanded memory capabilities, including 256 kB flash, 32 kB SRAM, and 8 kB data memory (EEPROM). Operating at 5 V, this board ensures compatibility with UNO form factor accessories designed for the same voltage. While previous UNO shields can be used, software compatibility may vary due to the microcontroller change. Experience the UNO R4 Minima’s cutting-edge performance and enhanced features today.


Features:

  1. 32-bit development board, being previously based on 8-bit AVR
  2. The board features the standard 14 digital I/O ports, 6 analog channels
  3. dedicated pins for I²C, SPI and UART connections.
  4. Larger memory:
    1. 8 times more flash memory (256 kB)
  5. 16 times more SRAM (32 kB).
  6. Easy power management:
    1. The UNO R4 has a barrel jack connector and supports input voltages from 6-24 V.
  7. This connector is widely popular and removes the need for additional circuitry required to step down the voltage.
  8. Cross compatibility:
    1. The UNO form factor automatically makes it compatible with hundreds of existing third-party shields and other accessories.

Note: For detailed technical Specifications go through Datasheet in the attachment section


Package Includes:

1 x Arduino UNO R4 Minima Board





Arduino UNO R3 VS R4 – Differences Explained in Detail

Difference UNO R3 UNO R4
Microcontroller 8-bit ATmega328p 32-bit Renesas RA4M1
Clock frequency 16 MHz 48 MHz
Wireless module NO *ESP32-S3 Mini
Memory 2KB SRAM, 32KB FLASH,
1KB EEPROM
256 kB Flash, 32 kB RAM
*ESP: 384 kB ROM, 512 kB SRAM
RTC NO YES
Input voltage (VIN) 6-20 V 6-24 V
Digital I/O pins 14
Analog input pins 6(10-bit) 6(14-bit)
PWM pins 6(8-bit) 6(12-bit)
DAC pin NO 1(12-bit)
CAN Bus NO 1
Dimensions 68.58 x 53.44 mm 68.6 x 53.4 mm
0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “Arduino UNO R4 Minima”

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

Get a discount when you buy more

Specification

Brand

Arduino

Model

Arduino UNO R4 Minima

Memory

256 kB Flash Memory
32 kB SRAM
8 kB Data Memory (EEPROM)

Pins

14x digital pins (GPIO), D0-D13
6x analog input pins (ADC), A0-A5
6x PWM pins: D3,D5,D6,D9,D10,D11

Peripherals

Capacitive Touch Sensing Unit (CTSU)
USB 2.0 Full-Speed Module (USBFS)
up to 14-bit ADC
up to 12-bit DAC
Operational Amplifier (OPAMP)

Power

Recommended input voltage (VIN) is 6-24 V
5 V operating voltage
Barrel jack connected to VIN pin
Power via USB-C® at 5 V
Schottky diodes for overvoltage and reverse polarity protection

Communication

1x UART (pin D0, D1)
1x SPI (pin D10-D13, ICSP header)
1x I²C (pin A4, A5, SDA, SCL)
1x CAN (pin D4, D5, external transceiver is required)
