Arduino mega 2560 ATmega2560-16AU Board

  1. 54 digital input / output terminals (14 of which have programmable PWM outputs).
  2. 16 analog inputs.
  3. 4 UARTs (hardware serial ports).
  4. 16 MHz crystal clock.
  5. Operating voltage: 6 ~ 12v.
  6. Dimensions: 110 x 53 x 15 mm.

Original price was: EGP1,740.00.Current price is: EGP1,300.00.

In stock

SKU: AA005 Categories: ,
Estimated delivery dates: 03-12-2024 - 05-12-2024

Arduino Mega 2560 follows Open-source principles, which means you can freely download the development environment and any associated resources.

Ideal for project work and often used in schools, teaching, motor control, robotics, and similar applications; the Arduino platform allows for rapid application development using either Java (cross-platform) or Processing (a C derivative used to write sketches using Arduino IDE downloadable from Arduino.cc website.)

Input voltage should be limited to 6 ~ 12V, but if the voltage supplied is less than 6V, I / O port may not be supplied to a voltage of 5V, and therefore readings may become unstable. If the voltage is greater than 12V, the regulator device may overheat causing damage to the control board. It is therefore recommended that you supply between 6.5 and 12V, utilizing typical power supplies of 7.5V or 9V.

The Mega 2560 ATmega2560-16AU Board plus USB Cable compatible with Arduino is fully compatible with the Arduino software and has complete hardware compatibility with the Arduino Shield high-performance processor and enough memory to handle even complex solutions.

Note: If you are getting the error while uploading the code in the Arduino mega or not detecting the port need to upload the bootloader. You can refer to the attached video for the bootloader.


Features :

  1. Bootloader – to allow downloading of ‘sketches’ via USB without having to go through other external writers.
  2. Powered from USB or via external PSU (not supplied). The device will automatically switch between power inputs.
  3. Heavy gold plate construction.

Package Includes :

1 x Arduino Mega 2560 Board

ARDUINO SCHEMATICS.

0 reviews
0
0
0
0
0

There are no reviews yet.

Be the first to review “Arduino mega 2560 ATmega2560-16AU Board”

Your email address will not be published. Required fields are marked *

You have to be logged in to be able to add photos to your review.

Get a discount when you buy more

Specification

Dimensions 110 × 53 × 15 mm
Brand

Arduino

Microcontroller

ATmega2560

EEPROM

4KB

Flash Memory

256 KB

SRAM

8

Analog I/O Pins

16

Digital I/O Pins

54 digital input / output terminals (14 of which have programmable PWM outputs)

PWM Output Pins

15

DC Current per I/O Pin (mA)

50

Architecture

Advanced RISC Architecture

Clock Speed

16 MHz

Input Voltage(Recommended)

7-12V

Operating Voltage (VDC)

5

Color:

Blue
