GY-471 MAX471 Current Sensor Module โ€“ 3A DC 0โ€“30V Bidirectional Current Measurement for Arduino & Microcontrollers - Ekostra Electronics In Egypt ุงูƒูˆุณุชุฑุง ุงู„ูƒุชุฑูˆู†ูŠูƒุณ

GY-471 MAX471 Current Sensor Module โ€“ 3A DC 0โ€“30V Bidirectional Current Measurement for Arduino & Microcontrollers

  • โšก GY-471 current sensor module based on MAX471
  • ๐Ÿ” Measures DC current up to 3A (bidirectional sensing)
  • ๐Ÿ”‹ Supports load voltage range: 0โ€“30V
  • ๐Ÿ“ˆ Analog output for easy reading with Arduino/MCU ADC
  • ๐Ÿงฉ Ideal for battery monitoring, power profiling, and motor current
  • ๐Ÿ›ก๏ธ Low insertion lossโ€”minimal impact on the load
  • ๐Ÿ› ๏ธ Simple wiring: VIN+, VIN-, VCC, GND, OUT
  • โœ… Great for power management and protection projects
SKU: AB1849 Categories: , Tags: , ,

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

165,00 EGP

Compare
12 People watching this product now!

Payment Methods:

Description

The GY-471 MAX471 3A Current Sensor Module is a compact and efficient solution for monitoring DC current and voltage in your projects.
Built around the MAX471 IC, this module provides bidirectional current sensing (both positive and negative currents) and outputs analog signals proportional to current and voltage.

It’s ideal for applications like battery monitoring, solar systems, motor control, and power management. The onboard shunt resistor ensures precise current measurement without the need for external components.

Simply connect it to your Arduino, ESP32, STM32, or Raspberry Pi ADC pin, and start reading real-time current and voltage data effortlessly.

โš™๏ธ Features

  • โšก Measures DC current up to 3A and voltage up to 30V

  • ๐Ÿ” Bidirectional current sensing capability

  • ๐Ÿ“ Built-in precision shunt resistor for accurate measurement

  • ๐Ÿ’ก Analog output for easy integration with ADCs

  • ๐Ÿ”Œ Compatible with 3.3V and 5V logic systems

  • ๐Ÿงฉ Compact, ready-to-use module design

  • ๐Ÿง  Ideal for battery management, solar charging, motor drivers, and power analyzers

๐Ÿ“Š Specifications

Parameter Description
Module Name GY-471 MAX471 Current Sensor
IC Model MAX471
Current Measurement Range 0 – 3A DC
Voltage Measurement Range 0 – 30V DC
Output Type Analog Voltage Output
Input Voltage 3V – 5V
Interface Type Analog
Accuracy ±1% (typical)
Operating Temperature -40°C to +85°C
Dimensions Approx. 27mm × 15mm × 5mm
๐Ÿ”Œ
Pin Connections
1 Table
Pin Connections Table 1
BoardSensor PinConnection
MAX471VCC/GND/VOUT/IOUT3.3-5V / GND / board analog pin / board analog pin
๐Ÿ“Ÿ
GY-471 MAX471 Current Sensor Module - 3A DC 0-30V Bidirectional Current Measurement for Arduino & Microcontrollers
7 Examples โ€ข C/C++ | Boards: Arduino Uno, Arduino Nano, Arduino Mega, ESP32, ESP8266, STM32, Raspberry Pi Pico
GY-471 MAX471 Current Sensor Module - 3A DC 0-30V Bidirectional Current Measurement for Arduino & Microcontrollers - Arduino Uno
GY-471 MAX471 Current Sensor Module - 3A DC 0-30V Bidirectional Current Measurement for Arduino & Microcontrollers - Arduino Nano
GY-471 MAX471 Current Sensor Module - 3A DC 0-30V Bidirectional Current Measurement for Arduino & Microcontrollers - Arduino Mega
