DC motor GW370 12V with encoder 80 RPM

Name: DC motor GW370 12V with encoder 80 RPM
SKU: Ek2068
Price: 675.00 EGP
Availability: InStock

DC Motor GW370 12V with Encoder 80 RPM
1. Voltage: 12V DC
2. Speed: 80 RPM (no-load)
3. Encoder: Incremental quadrature
4. Motor Frame: GW370
5. Gears: Metal

SKU: Ek2068 Category: DC Motor Tags: 12V motor, 80 RPM, DC Motor, DC motor | محرك تيار مستمر، GW370، محرك 12 فولت، 80 دورة في الدقيقة، محرك مزود بمشفر، محرك منخفض السرعة، مشغل روبوتات، مشفر رباعي, encoder motor, GW370, low speed motor, quadrature encoder, robotics actuator
