TCRT5000L 5 Channel Tracking Sensor Tracking Module Infrared Sensor
- 🧭 TCRT5000L 5-channel infrared tracking sensor module
- 🔦 5 IR reflective sensors for accurate line tracking
- 📏 Great for detecting black/white lines and edges
- ⚡ Works with 3.3V/5V controllers (module dependent)
- 🎛️ Adjustable sensitivity via onboard potentiometers (common design)
- 🤖 Ideal for line follower robots and smart car projects
- 🛠️ Easy interface with digital outputs to Arduino/MCU pins
- ✅ Perfect for robotics competitions and DIY tracking builds
180,00 EGP
17
People watching this product now!
Payment Methods:
Description
TCRT5000L 5 Channel Tracking Sensor Tracking Module Infrared Sensor is based on the TRCT5000 infrared reflection sensor, it is often used to make tracking smart cars. The infrared emitting diode of the TRCT5000 sensor continuously emits infrared rays. When the emitted infrared rays are reflected by the object, they are received by the infrared receiver and output analogue values. The output analogue value is related to the object distance and the colour of the object. The position of the tracking line is judged by calculating the analogue value of the five outputs.
Connection:
- VCC: VCC is the power input port, which could access 3.3V ~ 5V voltage
- GND: GND is the negative input of the power supply
- OUT1 ~ 5:OUT is the signal output port, MCU link I / O port
Features:
- Applicable to a variety of platforms including for Arduino /AVR/ARM/PIC
- High-Quality Tracker Sensor
- The module is a convenient carrier for eight IR emitter and receiver pairs evenly paced.
- Distance between each IR Sensor: 15mm
- Uses 5 sensors for best resolution
- Great useful in building fast line following and grid navigating robots
- Comes with easy to use digital outputs with a direct connection to microcontrollers
- The array has mounting holes of 3mm diameter for easy mounting
- Status LED on each sensor for the detection of black line
Package Includes:
1 x TCRT5000L 5 Channel Tracking Sensor Tracking Module Infrared Sensor
Specification
General
| WeightWeight | 0,0000 g |
|---|---|
 Dimensions | 4 × 2 × 1,5 cm |
| Product Name | TCRT5000L 5-Channel Tracking Sensor Module |
| Type | Infrared Line Tracking Sensor Module |
| Model | TCRT5000L |
| Number of Channels | 5 |
| Sensing Method | Infrared Reflective Sensor |
| Output Type | Digital (High/Low) |
| Operating Voltage | 3.3–5 V DC |
| Detection Distance | 1–3 mm (typical for reflective surfaces) |
| Response Time | <1 ms (typical) |
| Mounting Type | PCB Module / Through-Hole |
| Material | Plastic Housing with PCB and Sensor Components |
| Operating Temperature | -20°C to +70°C |
| Applications | Line Following Robots, Obstacle Detection, Arduino / Microcontroller Projects, DIY Robotics |
| Package Contents | 1× TCRT5000L 5-Channel Tracking Sensor Module |
