470uF 50V Radial Electrolytic Capacitor

This 470µF 50V radial electrolytic capacitor is a high-voltage decoupling and filtering component for power supplies operating on 24V to 48V DC buses. The 50V rating provides substantial voltage headroom, making it suitable for industrial control systems, motor drive circuits, and AC-DC converter output stages where capacitance in the hundreds of microfarads is needed at elevated voltages.

Constructed as a polarized aluminum electrolytic device with radial leads, this capacitor is intended for vertical through-hole PCB mounting. The 50V capability requires a larger case than lower-voltage equivalents, but delivers the voltage endurance and ripple current handling required for demanding power applications.

1. 470µF capacitance with ±20% tolerance
2. 50V DC working voltage rating for higher-voltage rails
3. Polarized aluminum electrolytic construction
4. Radial leads for standard PCB mounting
5. Capable of handling ripple currents in switching converters
6. Low ESR for effective high-frequency decoupling
7. Operating temperature: -40°C to +85°C
8. Suitable for industrial and automotive power stages
