Arduino Mega 2560 R3 Clone (CH340)

The Arduino Mega 2560 R3 Clone is an advanced Arduino development board based on the powerful ATmega2560 microcontroller. It offers significantly more input/output pins and features than entry-level Arduino boards like the Uno, making it ideal for complex projects such as 3D printers, robotics, and automation systems.

This clone version uses the CH340 USB-to-serial converter for reliable and cost-effective connectivity, compatible with the Arduino IDE.

Features

• Microcontroller: ATmega2560

• Operating Voltage: 5V

• Input Voltage (Recommended): 7-12V

• Input Voltage (Limit): 6-20V

• Digital I/O Pins: 54 (15 PWM outputs)

• Analog Inputs: 16

• DC Current per I/O Pin: 20 mA

• DC Current for 3.3V Pin: 50 mA

• Flash Memory: 256 KB (8 KB used by bootloader)

• SRAM: 8 KB

• EEPROM: 4 KB

• Clock Speed: 16 MHz

• Communication: 4 UART (hardware serial ports)

• USB Interface: CH340 USB-to-serial converter (faster and more memory efficient than older 8U2)

• Size: 101.52 mm x 53.3 mm

• Weight: 37 g

Advantages

• Large number of I/O pins for complex interfacing

• Compatible with all Arduino shields designed for Duemilanove and Diecimila

• Supports multiple serial ports for advanced communication

• Robust power supply options (USB, external adapter, battery) with automatic selection

• Open-source platform with extensive Arduino library support

Power Considerations

• Can be powered by USB or external source (6-20V)

• Recommended external power supply is 7-12V for optimal performance

• Using less than 7V can cause unstable 5V output

• Using more than 12V risks overheating the voltage regulator

Applications

• 3D printers and CNC machines

• Robotics and automation systems

• Data logging and sensor arrays

• Multi-device communication projects

• Large-scale embedded systems

Package Includes

• 1 x Arduino Mega 2560 R3 Clone (CH340) Board
