Arduino Nano V3.0 CH340 Chip Board,Atmega328P

  1. Operating Voltage (logic level): 5V
  2. With Soldered Connector
  3. 8 analog inputs ports: A0 ~ A7
  4. 14 Digital input / output ports: TX, RX, D2 ~ D13
  5. 1 pair of TTL level serial transceiver ports RX / TX
  6. Using Atmel Atmega328P-AU MCU
  7. There is a bootloader installed in it
  8. Standard 0.1” spacing DIP (breadboard friendly).
  9. Manual reset switch.
SKU: AA008 Categories: ,

EGP250.00

11 People watching this product now!
  • Pick up from the Ekostra Store

To pick up today

Free

  • Courier delivery

Our courier will deliver to the specified address

1-3 Days

50 LE

  • Free 14-Day returns

Payment Methods:

Description

Arduino Nano is a small motherboard based on the ATmega328P. It has about the same features as the Arduino Duemilanove, only it lacks a DC power jack. Arduino IDE application is needed
for programming . The Arduino Nano is powered by the Mini-B USB connection. The power supply automatically selects the high voltage source. The operating voltage is in the range of 5V – 12V. However, the recommended operating voltage should be more than 7V. 9V batteries will be sufficient for operation.

In this clone version of Arduino Nano board, CH340 IC is used instead of Standard FTDI or 16U2 chips.
Thus, the cost was reduced, but there was no change in performance.

Features:

  • Micro-Controller: ATmega328P
  • Operating Voltage: 5V
  • Input Voltage (recommended): 7-12V
  • Digital I/O Pins: 14 (6 of them to provide PWM output)
  • Analog Input Pins: 8
  • Flash Memory : 32 KB
  • Operating Frequency: 16 MHz
  • Dimensions : 19x43mm

Package Included:

  • 1 x Arduino Nano Clone CH340

Specification

Overview

Clock Speed

16 MHz

Color

Blue

DC Current per I/O Pin (mA)

40

Digital I/O Pins

22

EEPROM

1KB

Flash Memory

32 KB

Input Voltage(Recommended)

7-12 V

Microcontroller

ATmega328

Operating Voltage (VDC)

5

Power Consumption (Watt)

1

PWM Output Pins

6

SRAM

2

Brand

Arduino

Shipping Info

Weight

8.0000 g
