TIP136 80V 8A PNP Complementary Power Darlington Transistor
- 🔌 TIP136 PNP complementary power Darlington transistor
- 💪 High current capacity: up to 8A
- ⚡ Voltage rating: 80V
- 🔥 High power handling (with proper heatsink)
- 🧩 Ideal for switching/driving motors, relays, solenoids, and lamps
- 🔁 Darlington design for high gain—easy MCU control
- 🛠️ TO-220 package—simple mounting and cooling
- ✅ Great for power driver and high-side switching circuits
6,00 EGP
Only 1 left in stock
Only 1 left in stock
6
People watching this product now!
Payment Methods:
Description
Specification
General
| Weight Weight | 0,00 g |
|---|---|
| Product Type |
Darlington Power Transistor |
| Model |
TIP136 |
| Polarity |
PNP (Complementary to TIP131/TIP135 family) |
| Application |
High Current Power Switching / Amplification |
| Mounting Type |
Through-Hole |
| Package |
TO-247 / TO-218 (varies by manufacturer) |
| Pin Count |
3 |
| Pin Configuration |
B-C-E (front view, typical) |
| Collector-Emitter Voltage (VCEO) |
80 V |
| Collector Current (IC) |
8 A |
| Power Dissipation (PD) |
70–80 W (typical, depends on package & heatsink) |
| DC Current Gain (hFE) |
1000 (typical) |
| VCE(sat) |
2.0–2.5 V (typical @ IC=5 A) |
| Base-Emitter Voltage (VBE(on)) |
2.5–2.8 V (typical @ IC=5 A) |
| Transition Frequency (fT) |
3 MHz (typical) |
| Operating Junction Temperature (TJ) |
-65°C to +150°C |
| Applications |
High-side switching, DC motors, solenoids, power control |
