Terminal Block 3Pin 3.96mm Pitch
- 3.96mm pitch, 3-pin screw terminal
- Rated for 10A / 300V
- Accepts 18–24 AWG wires
- Through-hole, straight pin mount
- -40℃ to +105℃ temperature range
5,00 EGP
In stock
In stock
5
People watching this product now!
Payment Methods:
Description
| Manufacturer | Cixi Kefa Elec |
| Mfr. Part # | KF396-3.96-3P |
| Package | Straight,P=3.96mm |
| Datasheet | KF396-3-96-3P Datasheet |
| Description | 10A 0.75 -40℃~+105℃ 300V Green Straight pin 3.96mm 1 18~24 3 Straight,P=3.96mm Screw terminal ROHS |
Specifications
| Attribute | Value |
| Category | Connectors/Screw terminal |
| Datasheet | KF396-3-96-3P Datasheet |
| RoHS | |
| Current Rating (Max) | 10A |
| Wire Gauge – mm? | 0.75 |
| Operating Temperature Range | -40℃~+105℃ |
| Voltage Rating (Max) | 300V |
| Color | Green |
| Mounting Style | Straight pin |
| Pitch | 3.96mm |
| Number of Rows | 1 |
| Wire Gauge – AWG | 18~24 |
| Number of PINs Per Row | 3 |
Specification
General
| Weight Weight | 0,002 g |
|---|---|
Dimensions
|
1,2 × 1 × 0,8 mm |
| Product Name |
Terminal Block 3Pin 3.96mm Pitch |
| Type |
Screw Terminal Block Connector |
| Number of Pins |
3 |
| Pitch |
3.96 mm |
| Current Rating |
10A (typical) |
| Voltage Rating |
250V AC / 300V DC (typical) |
| Wire Gauge |
28–12 AWG |
| Mounting Type |
Through-Hole |
| Material |
Nylon / Plastic Body with Metal Contacts |
| Operating Temperature Range |
-40°C – +105°C |
| Color |
Green |
| Applications |
PCB Connections, Power Supply, Arduino / DIY Electronics |
| Package Contents |
1× 3Pin 3.96mm Pitch Terminal Block |
