The IC 7425 is a TTL logic IC that contains two independent 4-input NOR gates in a single 14-pin DIP package. Each gate performs the NOR logic operation, outputting a LOW signal when any of its four inputs is HIGH—making it a vital component in logic design and control systems.
Designed using TTL (Transistor-Transistor Logic) technology, the 7425 offers fast switching speeds and is commonly used in high-speed digital circuits and industrial logic controllers.
Key Features
-
Dual 4-input NOR gates in one package
-
TTL-compatible logic levels
-
Fast switching response
-
Low power dissipation
-
Standard DIP-14 package for easy prototyping
-
Ideal for digital control, signal processing, and educational circuits
Specifications
| Parameter | Value |
|---|---|
| IC Model | 7425 |
| Logic Function | Dual 4-input NOR gates |
| Logic Family | 74 Series TTL |
| Number of Gates | 2 |
| Supply Voltage | 4.75V to 5.25V (Typically 5V) |
| Input Logic Level HIGH | Min. 2V |
| Input Logic Level LOW | Max. 0.8V |
| Output Current | ±8 mA typical |
| Package Type | DIP-14 |
| Operating Temperature | 0°C to +70°C |
| Compatibility | Breadboards, TTL logic systems, Arduino (via level shifting) |
Package Includes
1 × 7425 Dual 4-Input NOR Gate IC (DIP-14 Package)
