Battery Charger for 18650 Li-ion 1 Cell YH-07
-
Designed for 1×18650 Li-ion battery (3.7V)
-
Compact and portable charging dock
-
LED indicators: Red (charging), Green (fully charged)
-
Built-in protection: overcharge, short-circuit, reverse polarity
-
USB-powered – compatible with wall adapters, laptops, power banks
-
Ideal for flashlights, DIY projects, and battery testing
50,00 EGP
In stock
In stock
Payment Methods:
Description
YH-07 18650 Li-ion Battery Charger – Single Cell Charging Dock
The YH-07 Battery Charger is a compact and efficient charging solution designed specifically for 18650 Li-ion batteries. Whether you’re building battery packs, working on DIY projects, or need a reliable charger for everyday use, the YH-07 provides a simple and safe way to recharge a single 3.7V Li-ion cell.
This charger features automatic charge control, LED indicator lights, and a standard USB input, making it convenient for use with USB wall adapters, laptops, or power banks.
Key Features
-
Designed for 1×18650 Li-ion cell (3.7V)
-
Compact and portable charging cradle
-
LED indicators: Red (charging), Green (fully charged)
-
Built-in protection against overcharge, short circuit, and reverse polarity
-
Powered via standard USB port (5V input)
-
Ideal for flashlights, DIY projects, and battery testing
Specifications
| Parameter | Value |
|---|---|
| Model | YH-07 |
| Battery Compatibility | 18650 Li-ion (1 cell) |
| Input Voltage | 5V DC (USB) |
| Output Charging Voltage | 4.2V DC |
| Charging Current | ~1A (typical) |
| Indicators | Red = Charging / Green = Full |
| Protection Features | Overcharge, Short-Circuit, Reverse Polarity |
| Dimensions | Approx. 96 × 34 × 32 mm |
Package Includes
-
1 × YH-07 Single Cell 18650 Battery Charger
🔋 Tip: Use a quality USB adapter (5V/1A or higher) for optimal charging performance.
Specification
General
| Weight Weight | 0,0000 g |
|---|---|
Dimensions
|
7 × 4 × 2,5 mm |
| Product Name |
Battery Charger for 18650 Li-ion 1 Cell YH-07 |
| Type |
Li-ion Battery Charger |
| Compatible Battery |
18650 Li-ion (Single Cell) |
| Input Voltage |
100–240V AC, 50/60Hz |
| Output Voltage |
4.2V DC |
| Output Current |
500 mA – 1000 mA (adjustable depending on charger model) |
| Charge Mode |
Constant Current / Constant Voltage (CC/CV) |
| LED Indicator |
Charging / Fully Charged Status |
| Protection |
Overcharge, Short Circuit, Reverse Polarity |
| Operating Temperature Range |
0°C – +45°C |
| Mounting Type |
Desktop / Portable |
| Material |
ABS Plastic Casing |
| Color |
Black |
| Applications |
Charging 18650 Li-ion Batteries for Flashlights, DIY Electronics, Power Banks |
| Package Contents |
1× YH-07 18650 Li-ion Single Cell Battery Charger |
