7408 Quad 2-input AND Gate
14,00 EGP
In stock
- Contains four independent 2-input AND gates
- Operates at standard 5V TTL logic levels
- Performs logical AND on two inputs per gate
- Fast switching with low propagation delay
- Available in 14-pin DIP or SMD packages
In stock
Shipping & Delivery
Receipt from the place on the same day or shipping to nearby places
On the same day
6PM - 10 PM
Delivery through a fast shipping company intermediary
1-3 Days
Description
Features
- Four 2-Input Logic AND Gates
- Outputs Directly Interface to CMOS, NMOS and TTL
- Large Operating Voltage Range
- Wide Operating Conditions
Pin Layout
7408 Quad 2-Input AND Gate – Product Overview
The 7408 IC contains four independent 2-input AND gates. Each gate performs a basic AND logic function, outputting HIGH only when both inputs are HIGH. This TTL logic IC is commonly used in digital circuits to implement AND logic operations efficiently.
⚙️ Key Features
-
Contains 4 independent 2-input AND gates
-
Standard TTL logic compatible
-
Typical propagation delay: ~10 ns
-
Operates on 5V supply voltage
-
Available in 14-pin DIP package
-
Low power consumption
📋 Specifications
| Parameter | Description |
|---|---|
| IC Number | 7408 |
| Number of Gates | 4 |
| Inputs per Gate | 2 |
| Output Type | Standard TTL |
| Operating Voltage | 4.75V to 5.25V (Typically 5V) |
| Propagation Delay | Approx. 10 ns |
| Package Type | DIP-14 |
🔌 Pin Configuration (14-pin DIP)
| Pin | Name | Function |
|---|---|---|
| 1 | 1A | Input 1 Gate 1 |
| 2 | 1B | Input 2 Gate 1 |
| 3 | 1Y | Output Gate 1 |
| 4 | 2A | Input 1 Gate 2 |
| 5 | 2B | Input 2 Gate 2 |
| 6 | 2Y | Output Gate 2 |
| 7 | GND | Ground |
| 8 | 3Y | Output Gate 3 |
| 9 | 3A | Input 1 Gate 3 |
| 10 | 3B | Input 2 Gate 3 |
| 11 | 4Y | Output Gate 4 |
| 12 | 4A | Input 1 Gate 4 |
| 13 | 4B | Input 2 Gate 4 |
| 14 | VCC | Power Supply (+5V) |
Truth Table (Each Gate)
| Input A | Input B | Output Y |
|---|---|---|
| 0 | 0 | 0 |
| 0 | 1 | 0 |
| 1 | 0 | 0 |
| 1 | 1 | 1 |
Applications
-
Digital logic circuits requiring AND functions
-
Combinational logic designs
-
Control systems and decision-making circuits
-
Building blocks for arithmetic and logic units
Package Includes
-
1 × 7408 Quad 2-Input AND Gate IC (DIP-14)
